x8086NetEmu is a VB.NET implementation of an almost working 8086 emulator...
Although it still has some bugs, it is a fairly stable and capable 8088/86/186 emulator

Features

* Full 8086 architecture emulation: CPU, Memory, Flags, Registers and Stack
* Peripherals: PIC/8259, PIT/8254, DMA/8237 and PPI/8255
* RTC, 8087, Serial/Mouse and VGA are currently being implemented and some are partially working
* Adapters: CGA, Speaker and Keyboard
* Integrated Debugger and Console
* Support for both Floppy and Hard Disk images
* No BIOS hacks required
* WinForms and Console samples included
* Hard disk and floppy images inspector (FAT12 and FAT16 support only and quite buggy)

Notes

includes two executables:

x8086NetEmuWinForms: This version will run under a WinForm form and will use GDI+ to render the text and graphics.
x8086NetEmuConsole: This version uses the Windows console to render the text. You can improve the rendering by using an appropriate font for the console.
